AUDIOLINK Network Audio System POE Loudspeaker

Audiolink protocol
CAT5 cable to provide power and audio signal
Ceiling Mount


This model of speaker is installed on the ceiling, simply connecting with VISSONIC conference controller by CAT5 cable to provide power and audio signal. It is used to convert the input audio electric power signal of the power amplifier (referred to as the power amplifier or amplifier) into a sound power signal and then broadcast it through the ceiling speaker in the form of sound waves. Ceiling speakers are widely used at Office buildings, hotels, and shopping malls are public places that use ceiling speakers.
It's suitable for high-end performances, conferences, evenings and concert system.


Effective frequency range (-10dB): 70Hz-20kHz
Speaker unit: LF: 1x8"(1"voice coil), HF: 1x1"(1" neodymium voice coil)
Rated impedance (±20%): 8Ω
Characteristic sensitivity level (±2dB): 90dB/w/m
Sound pressure level in the designated frequency band (±2dB): > 104dB
Total harmonic distortion:<1%
Covering angle (horizontal/vertical): 90°x90°
Socket: 1*RJ45 interface
Power: 120W
Power supply: PoE DC48V 40W 8 ohms
Power amplifier protection function: load short circuit protection.
Other protection functions of the power amplifier: overcurrent protection/overtemperature protection/overload, natural convection heat dissipation
Using AUDDIOLINK digital audio transmission technology, no compression, no loss; network IP architecture, realizing digital audio system.
Built-in DSP processing, each speaker has 8-band EQ equalization, gain, limiter, filter, mute control and other functions;
Installation method: snap-in
Cabinet material: ABS+iron
Net weight: 5.9kg
Size: Φ281x261mm, Hole size: Φ246mm, Hole depth: 263mm
