4K60 HDMI 8x9 Seamless Matrix and Video Wall Processor


4K Signal management Products 4K60 HDMI 8x9 Seamless Matrix and Video Wall Processor

Up to 4K@60, 4:4:4

8 HDMI inputs, 9 HDMI outputs

Input Image Clipping

Station Logo Display

Support Scrolling Text

HDMI to DVI Interface Format Correction

VIS-UHD0809-VW is professional seamless UHD matrix switcher with 8x9 HDMI input/output video wall processor. It provides high peak data transfer rate and perfectly supports synchronous switching of HDMI signals, resolution up to 4K@60,4:4:4 , create creative video wall layouts through an intuitive web GUI, FPGA-based pure hardware structure, can be widely used in stage presentations, digital classroom, video conference rooms etc.


● 8 HDMI inputs, 9 HDMI outputs, Realtime seamless switching

● 8 IR and 8 analog audio inputs, 9 IR and 9 analog audio outputs

● Input and output support up to 4K@60,4:4:4 , backward compatible

● 4K scaler converts the input resolution to the monitor’s native resolution

● Input image clipping

● Station logo display

● Input selectable test images

● Output matrix or single layer splicing

● Output selectable test images

● Support LED splicing

● Support scrolling text

● Independent audio and IR switching

● Graphical web control

● Full digital seamless switching technology

● Multiple control methods including front key panel with LCD control, RS232 control and TCP/IP control with RJ45 ports, make control more flexible

Related Products:

Related recommendations:

8x9 HDMI Matrix--Full 18G signal processing throughout the entire signal path, from input to output. Capable of handling HDR signals and resolutions up to 4K60 4:4:4 with a total bandwidth of 18Gbps

● Video Wall -- create creative video wall layouts through an intuitive web GUI, multiple monitors can be easily configured to display video as one big screen.

● 4K Scaler -- 4K scaling technology that converts various input resolutions to the monitor's native resolution, providing viewers with the best picture and video quality.

● Seamless Switching -- FPGA-based pure hardware structure can provide high peak data transfer rate up to 4K@60 and perfectly supports synchronous switching of HDMI signals.

● Input volume control -- Provides volume control for the audio inputs, so when we changed the volume, every outputs from this inputs changed.

 HDMI to DVI Interface Format Correction -- Automatically reformats HDMI source signals for output to a connected DVI display

 Automatic input cable equalization  -- Actively conditions incoming HDMI signals to compensate for signal loss when using long cables, low quality cables, or source devices with poor HDMI signal output. 4K/60 signals are equalized to 35 feet (10.7 meters) when used with HDMI 2.0 Pro cables.

 Automatic output reclocking -- Reshapes and restores timing of HDMI signals at each output, enabling transmission over long HDMI cables.

Provides +5 VDC, 250 mA power on the HDMI outputs for external peripheral devices

● Output muting control -- Provides the capability to mute one or all outputs at any time. This allows, for example, content to be viewed on a local monitor prior to appearing on the main presentation display

● Ethernet monitoring and control  -- Can be proactively monitored, managed, or controlled over a LAN, WAN, or the Internet using standard TCP/IP protocols.

● Station logo -- add a station logo for each input signal, making it easy to distinguish different inputs.

● Splicing subtitles -- Can add scrolling subtitles or welcome slogans to the splicing wall.

● Input Test Image  -- Input can automatically generate test images for engineering debugging and testing purposes

 Output Test Image -- Output test images to test whether the output ports and display devices are connected properly

● Splicing synchronization -- Support frame synchronization to ensure perfect synchronization of various output units

 Audio Embedder and De-embedder  -- The analog audio can embed into the HDMI signals or de-embed from the HDMI signals.

● EDID Management -- The monitor EDID can copy to the input port or we can update a available EDID file to the input port.

 Pre-Sets  -- The matrix can be stored 8 different Pre-sets, we can call it quickly through the panel buttons or RS232.

 Panel locking  -- We can set panel into “locking” to prevent accidental switching.

● IR Matrix -- Independent IR switching

● Audio Matrix -- Independent audio switching

● Web GUI -- Offers refined simplistic control of parameters.

● Front panel -- Control of all video routing, Pre-sets save and recall, IP Management, Check or set the net parameters
