NETLINK Paperless Multimedia System Ultra-thin HD Lifting Screen

Synchronous lifting/asynchronous lifting
Online whiteboard/document saving
Simultaneous presentation/one-key projection
Optional (speaking/voting/simultaneous interpretation/built-in sign-in or IC card)

Overview


Ultra-thin monitor lift is designed for advance multi-purpose paperless meeting rooms.When having the general meeting, the LCD can be hidden in the conference table to keep the desk clean and beautiful.The LCD can be used to display multimedia information alone, or in groups or all lifted in accordance with different needs,including conference content,information tips and image information and so on.

According to the different requirements of the meeting, the lifter can be controlled separately or in group through setting.

Features



Up, down, stop of the lifter can be controlled by the panel button, remote control and central controller.

When the lifter reaches the top, the LCD will turn to angle of elevation automatically.

When the LCD screens drops, the lifter will close the door automatically.

When the lifter drops, the door starts anti-pinch function.

The lifter can realize remote control by RS232, RS485 protocol

Specifications



Model Number

VIS-15LSSC

VIS-17LSSC

VIS-18LSSC

VIS-21LSSC

Panel size(mm)

430*70*3

476*70*3

510*70*3

582*70*3

Bottom Case(mm)

415*60*562

462*60*562

495*60*647

567*60*647

Screen size

15.6inch

17.3inch

18.4inch

21.5inch

Product Weight

7.5KG

8.5KG

9.5KG

12KG

Package Size

48.8x 13.2x 66cm

53.8x 13.2x 66cm

56.5x 13.2x 74.5cm

 63.5x13.2x 74.5cm

Gross Weigh

8.5KG

9.5KG

10.5KG

13KG



Diagram



Ultra-thin HD Lifting Screen(图1)
