Dante 2×2 Audio Matrix
VIS-DAN22
2×2 Dante Interface
Phantom Power Support
PoE & Web Control
Overview
The VIS-DAN22 is a Dante network audio interface that seamlessly integrates 2x2 Dante audio channels into networked audio systems. Each input channel is equipped with a 48V phantom power option. It supports PoE power supply and features a compact design, making it easy to deploy Dante connectivity wherever it is needed.
Features
•2 analog inputs and 2 analog outputs
•Control method: Controlled by Web-UI and Dante controller, users can easily configure and operate the audio matrix on the web page or through a dedicated controller to achieve flexible routing, mixing and other functions
•Gain adjustment: Supports adjustment of each input gain from 0dB to +48dB, and can flexibly adjust the strength of the input signal to adapt to different audio sources and application scenarios.
•Phantom power: Provides 48V phantom power for microphone input, which is convenient for connecting condenser microphones that require phantom power to ensure the normal operation of the microphone.
• 2 analog inputs and 2 analog outputs for line/mic levels.
• Supports adjustable gain for each input in the range of 0 ~ +48dB.
• Output volume control range is -60dB to 0dB.
• 48V phantom power for each input channel.
• Powered by PoE(IEEE802.3af).
• Supports 44.1k or 48k audio sampling rate.
• Controllable via Dante controller and Web UI.
